Subsonic Aircraft Research
Synopsis of research from September 2020 to present

Research Title : Feature on Wing Flap to Enhance Aerodynamic Efficiency

Product Concept R03 is a revolutionary wing flap feature that enhances aerodynamic efficiency and has the potential to improve the performance of aircrafts. Developed by an exceptional Core Research Team, this product has a provisional patent and application number 202021047472.



The twin-flap system that constitutes Product Concept R03 is designed to have two symmetric flaps with individual dominance. The angle enhancement of the flap increases the efficiency in a sine-wave fashion with continuous increase in wavelength. The efficiency with different experimental angles keeps on shifting the optimum point and an unexpected low-pressure region is observed over some specific area of the wing.



The behaviour of the twin-flap system is dependent on the volumetric expansion of the feature and high efficiency also induced fluctuation in efficiency over local velocity ranges. The control-and-optimized volumetric expansion of the feature can merge fluctuation and constant region resulting in a single stable-and-high efficiency region. Currently, 3:2 is the most suitable ratio for the enhancement of the feature considering the aerodynamicity.



The enhanced feature is attached to the flap of the wing and is demonstrated as a major geometrical parameter which alters the overall performance of the wing. The insufficient aerodynamicity of the feature not only affects the performance of the wing but also decreases its stability. Additionally, the twin-flap system with an enhanced feature has a significant effect on efficiency and the efficiency is the function of twin-flaps and the enhanced feature.



The effect of enhanced feature is clearly visible and 3:2 (not to be swapped with direction) still remains the most suitable ratio for the enhancement of the feature considering the aerodynamicity. The study of the dual flaps helps in better understanding the effect of operational conditions.



A mathematical model has been developed to predict the contribution of inter-dependent variables. The twin-flaps show independent contribution in parabolic form in accordance with the change in efficiency. The enhanced performance of each of the flap with the addition of feature is clearly visible for a wide range of testing.



Independent study of twin-flaps with feature shows that the peak performance of the flaps is the function of feature design and occurs at different angles of operation. The contribution of alpha flap increases when moved from lower to higher AOA and the contribution of beta flap increases with the increment of AOA.



Even though the performance stability of alpha flap is less than the beta flap, the alpha flap has a higher contribution in increasing the overall efficiency as compared to beta flap. Feature enhancement ratio 3:2 still remains the most versatile ratio and also outperforms the rest of the ratio even in the condition where the contribution of flaps gets reduced.



Product Concept R03 is a revolutionary product that has the potential to change the game in the aeronautics industry. It is a breakthrough technology that increases efficiency and maintains aggregate. The Core Research Team has done an exceptional job in developing this product, and it has the potential to revolutionize the industry.

Subsonic Aircraft Research
Product Concept R03 | Stage XXXIX Achieved | R&D April 2024
01:02

Product Concept R03 | Stage XXXIX Achieved | R&D April 2024

The current findings illuminate the intricate relationship between feature geometry and aircraft efficiency, particularly at higher angles of attack (AoA). The observed dramatic fluctuations in efficiency in a prototype featuring a fillet edge tail suggest a heightened sensitivity to variations in AoA, highlighting the importance of tail design in influencing performance. Furthermore, the competitive efficiency levels demonstrated by prototypes equipped with aerodynamic tails showcase the effectiveness of this design approach. However, the stability exhibited by one specific prototype with a full aerodynamic tail underscores the robustness of this configuration in maintaining efficiency across diverse conditions. These insights emphasize the critical role of feature geometry in shaping aircraft efficiency and warrant further investigation for optimization and improvement in future research endeavors.
Product Concept R03 | Stage XXXVIII Achieved | R&D March 2024
00:50

Product Concept R03 | Stage XXXVIII Achieved | R&D March 2024

Analysis conducted at higher AOAs, incorporating varying alpha and beta values, reveals a consistent trend: prototypes with triangular pointy tails, whether straight or curved, exhibit superior efficiency. This advantage stems from the aerodynamic benefits of the triangular shape, including optimized airflow control, reduced drag, and enhanced flight stability. Features like fillet edge tails and aerodynamic tails further contribute to efficiency by minimizing turbulence and optimizing lift distribution. These findings underscore the critical role of feature geometries in enhancing aircraft efficiency, suggesting avenues for future optimization.
Product Concept R03 | Stage XXXVII Achieved | R&D February 2024
01:02

Product Concept R03 | Stage XXXVII Achieved | R&D February 2024

Analysis of efficiency across prototypes with different feature geometries reveals distinct performances. Notably, prototypes featuring triangular pointy tails, whether straight or curved, exhibit superior efficiency compared to counterparts with full aerodynamic, partial aerodynamic, or other tail designs. This heightened efficiency is attributed to inherent aerodynamic advantages of the triangular shape, enhancing airflow control, reducing drag, and improving stability. Additionally, features like fillet edge tails and aerodynamic tails contribute to efficiency by minimizing turbulence and optimizing lift distribution. Thus, these geometries offer superior performance due to their favorable aerodynamic characteristics, presenting opportunities for further optimization to enhance overall aircraft efficiency.
Product Concept R03 | Stage XXXVI Achieved | R&D January 2024
01:01

Product Concept R03 | Stage XXXVI Achieved | R&D January 2024

While studying alpha, it is intriguing to note that the prototype featuring a full aerodynamic tail of the feature at a higher angle of attack (AOA) exhibits heightened efficiency. This highlights the aerodynamic advantages of a streamlined feature tail design in optimizing lift-to-drag ratios under increased AOA conditions. Concurrently, when studying beta, diverse efficiency performances emerge for prototypes with full, partial, and fillet edge feature tails. This reveals the intricate interplay of aerodynamic features in mitigating drag and enhancing overall efficiency across various flap angle configurations. These findings underscore the complexity of aerodynamic interactions and suggest potential avenues for optimization to elevate overall aircraft performance according to specified design parameters.
Product Concept R03 | Stage XXXV Achieved | R&D December 2023
00:50

Product Concept R03 | Stage XXXV Achieved | R&D December 2023

Diverse tail designs in subsonic aircraft show distinct performances based on alpha and beta values. The full aerodynamic tail prototype consistently demonstrates competitive efficiency, the partial aerodynamic tail prototype exhibits moderate variation, and the fillet edge tail prototype performs well with sensitivity to beta values. The 45-degree triangular (straight) pointy tail shows good overall performance, and the 80-degree triangular (straight and curved) pointy tails demonstrate competitive efficiency. These findings underscore the significance of tail design, suggesting potential for optimization through further research and specific design trade-offs.
Product Concept R03 | Stage XXXIV Achieved | R&D November 2023
00:46

Product Concept R03 | Stage XXXIV Achieved | R&D November 2023

The analysis of prototypes featuring different tail geometries reveals varying efficiencies. The prototype with a full aerodynamic tail demonstrates competitive performance, reaching its peak efficiency. The model featuring a partial aerodynamic tail shows moderate efficiency variation with a peak efficiency. Equipped with a fillet edge tail, another prototype exhibits efficiency showcasing some variability. The findings emphasize the significance of tail geometry in influencing the overall efficiency of subsonic aircraft prototypes, offering insights for potential optimizations in future designs.
Product Concept R03 | Stage XXXIII Achieved | R&D October 2023
00:57

Product Concept R03 | Stage XXXIII Achieved | R&D October 2023

The analysis of subsonic aircraft feature geometries revealed variations in efficiency. Among these geometries, prototypes with triangular pointy tails, whether straight or curved, consistently outperformed others. Their aerodynamic efficiency, which allows for smoother airflow control and reduced drag, results in improved overall efficiency. The pointed tail design also enhances stability during flight, crucial for efficient performance across various flight conditions and maneuvers. Additionally, the triangular tail geometry minimizes turbulence, reducing disruptive forces and ensuring a stable and efficient flight. These characteristics collectively make triangular pointy tail geometries the optimal choice for subsonic aircraft, particularly in scenarios where peak performance is essential.
Product Concept R03 | Stage XXXII Achieved | R&D September 2023
00:29

Product Concept R03 | Stage XXXII Achieved | R&D September 2023

Based on the latest data, certain prototypes have demonstrated exceptional performance under flight run conditions, effectively preventing local turbulence formation through consistent laminar flow along specific streamline features, offering a significant advantage. When analyzing various feature geometries, the prototype with a triangular pointy tail (whether straight or curved) outperforms others due to its aerodynamic advantages, enhancing airflow control, reducing drag, and improving stability. Further research could optimize these geometries for even better performance enhancements.
Product Concept R03 | Stage XXXI Achieved | R&D August 2023
00:44

Product Concept R03 | Stage XXXI Achieved | R&D August 2023

The analysis of various feature geometries' efficiency reveals insights into their performance. Among them, the 80-degree triangular (curved) pointy tail prototype stands out with the highest efficiency. This is due to its aerodynamic advantages, enhancing airflow control, reducing drag, and improving stability. While other geometries like those with fillet edge tails or partial aerodynamic tails show slightly lower efficiency, the 80-degree triangular (straight) pointy tail prototypes also perform well. These findings suggest that the curved variant offers the best performance, potentially through its unique aerodynamic characteristics. Further research could explore optimizing these geometries for even better efficiency.
Product Concept R03 | Stage XXX Achieved | R&D July 2023
00:43

Product Concept R03 | Stage XXX Achieved | R&D July 2023

The analysis of different feature geometries reveals varying performances in terms of efficiency. Among the different geometries, the prototype with a triangular pointy tail (either straight or curved) shows superior performance compared to other geometries. This improved performance can be attributed to the aerodynamic advantages offered by the triangular shape, which enhances airflow control, reduces drag, and improves stability. Additionally, the incorporation of specific features like fillet edge tails and aerodynamic tails also contributes to improved efficiency by reducing turbulence and optimizing lift distribution. Thus, these feature geometries exhibit better performance due to their favorable aerodynamic characteristics and their ability to enhance overall aircraft efficiency. In future research, further optimization of these feature geometries can be explored for even greater performance enhancements.
Product Concept R03 | Stage XXIX Achieved | R&D June 2023
00:32

Product Concept R03 | Stage XXIX Achieved | R&D June 2023

According to the latest data, certain prototypes have demonstrated excellent performance under flight run conditions, specifically when subjected to a non-zero angle of attack. These prototypes have effectively prevented the formation of local turbulence, likely due to the consistent maintenance of a good laminar flow along the streamline length of a particular feature. The absence of local turbulence is a significant advantage. However, further investigation is required to thoroughly examine the impact and benefits of the streamline length of this feature at higher angles of attack.
Product Concept R03 | Stage XXVIII Achieved | R&D May 2023
00:32

Product Concept R03 | Stage XXVIII Achieved | R&D May 2023

The current data show that the feature attached to the wing increases the overall efficiency of the flight (at non-zero angle of attack condition) while maintaining its performance. However, during the flight-run condition it became apparent that the feature can dramatically degrade performance by introducing the local turbulence. This scenario is unfavorable. The magnitude of the local turbulence has to be analyzed further.
